JR-MBR-15-D24

Customizable design available.

JR— MBR — MA — D MC

MA: Membrane area ≤ 35 ㎡

D:Single-row membrane frame

MC: Number of membrane curtains ≤ 30 pcs

Model	Total Membrane Area (m²)	Permeate Flow Rate (m³/d)	Recommended Operating Capacity (m³/d)	Dimensions (L × W × H, mm)	Inlet / Outlet Connection	Rack Weight (approx., kg)	Module Dry Weight (approx., kg)	Operating Wet Weight (approx., kg)
JR-MBR-15-D24	360	80-120	100	21207001750	DN50/DN50PN10	93	240	600

Typical Filtration Performance
Permeate turbidity	≤ 0.5 NTU
SDI₁₅	≤ 5.0
E. coli	Not detected
Total bacteria count	≤ 3 CFU/mL
